x11 windows display is out of screen for pi4 hardware res 1.4
hi all, sorry to bother you again, I am playing pi4 hardware res 1.4, meta-rasberrypi commit 1014d41ef459af807f95cb7ff9105f077bc6daa I am using a 13.3" LCD Lilliput TK1330-NP/C/T screen (mode :https://lilliputdirect.com/TK1330-NP-C-T-OF ). before the pi4 res 1.2 and older meta-rasberrypi worked well.
but for the pi4 hardware res 1.4, for DVI port as input, the menu display position seems OK, but the display is not clear and some color points for display. for HDMI port as input, the menu top position is a little out of the screen. we need resolution 1280X720. I tried a few resolutions, eg 1920x1080 .. all of them are out of the screen at the top side.
please the attached picture, at the top, I should show 3 -- but only 2 --, the top is out of the screen.
see more picture: please waiting booting is not show all
my resolution settings, I think it's corrent, because DVI as input port is OK, why HDMI is bad? my 18.5' and 10 '' different company's monitor work well.
any help? can I use the older driver? if OK, what files do I need to replace by the older driver?
Thank you very much.
root@raspberrypi4-64:~# xrandr
Screen 0: minimum 320 x 200, current 1280 x 720, maximum 7680 x 7680
HDMI-1 connected primary 1280x720+0+0 (normal left inverted right x axis y axim
1280x720_60.00 59.86*+
1920x1080 60.02
1680x1050 59.88
1680x945 60.02
1400x1050 59.95
1600x900 60.00
1280x1024 60.02
1440x900 59.90
1280x960 60.00
1360x768 60.02
1280x800 59.91
1152x864 59.97
1280x768 59.99
1280x720 60.00
1024x768 60.00
1024x576 59.97
800x600 60.32
640x480 59.94
cat /etc/X11/xorg.conf.d/10-monitor.conf
Section "Monitor"
Identifier "HDMI-1"
Modeline "1280x720_60.00" 74.50 1280 1344 1472 1664 720 72c
EndSection
Section "Screen"
Identifier "Screen0"
Device "HDMI-1"
Monitor "HDMI-1"
DefaultDepth 24
SubSection "Display"
Depth 24
Modes "1280x720_60.00" "1024x768"
EndSubSection
EndSection
Hi all, we added a adapter , it works. like the following connection:
PI4 --------micro HDMI ----------HDMI ------ HDMI to DVI adapter ------- DVI input ------- 13" display that's a hardware solution. so any other software solutions?
